ABB REL650 Product Guide

18. Connection diagrams
GUID-CF4EFFA5-3081-4FC7-9A14-ED127C3C0FDE v6
The connection diagrams are delivered in the IED Connectivity
package as part of the product delivery.
The latest versions of the connection diagrams can be
downloaded from
http://www.abb.com/protection-control.
Connection diagrams for Configured products
Connection diagram, REL650 2.2, A11X00
1MRK006507-LA
Connection diagram, REL650 2.2, A12X00 1MRK006507-LB
Connection diagrams for Customized products
Connection diagram, 650 series 2.2 IEC 1MRK006501-AG
Connection diagram, 650 series 2.2 ANSI 1MRK006502-AG
1MRK 506 384-BEN A
Line distance protection REL650 2.2
Product version: 2.2.1
ABB 31
