ABB REL650 Product Guide

20. Ordering for pre-congured IED
GUID-970741C9-5C16-4350-8FD6-106EE3BCECC5 v3
Guidelines
Carefully read and follow the set of rules to ensure problem-free order management.
Please refer to the available functions table for included application functions.
PCM600 can be used to make changes and/or additions to the delivered factory configuration of the pre-configured.
To obtain the complete ordering code, please combine code from the tables, as given in the example below.
Example code: REL650*2.2-A11X00- P23-B1A12-AA-CA-B-A3-CD1AX-KXXXXXLXGX. Using the code of each position #1-11 specified as REL650*1-2 2-3-4 4-5 6-7
7-8-9 9-10 10 10 -11 11 11
# 1 - 2 - 3 - 4 - 5 6 - 7 - 8 - 9 -
REL650* 2.2 - - - - - - - -
10 - 11
- X
Position
SOFTWARE #1 Notes and rules
Version number
Version no.
2.2
Selection for position #1
Conguration alternatives Ordering no #2 Notes and rules
Single breaker, 1/3 phase tripping 1MRK008003-CG A11
Single breaker, 1/3 phase tripping, isolated or high impedance earthed systems 1MRK008003-EG A12
ACT configuration
ABB Standard configuration X00
Selection for
position #2
Software options Ordering no #3 Notes and rules
IEC 62439-3 Parallel redundancy protocol 1MRK004001-PP P23 Options P23 and P24 require two
SFPs placed in pairs.
IEC 62439-3 High-availability seamless redundancy 1MRK004001-PR P24
IEC 61850-9-2 Process Bus communication, 4 merging units 1MRK004001-PU P31
Selection for
position #3
Language Ordering no #4 Notes and rules
First local HMI user dialogue language
HMI language, English IEC 1MRK002930-AA B1
Additional local HMI user dialogue language
No additional HMI language X0
HMI language, English US 1MRK002920-UB A12
Selection for
position #4
B1
Casing Ordering no #5 Notes and rules
1/2 x 19" rack casing, 1 TRM 1MRK000151-VA A
Selection for
position #5
A
1MRK 506 384-BEN A
Line distance protection REL650 2.2
Product version: 2.2.1
ABB 83
