ABB REL650 Product Guide

Control and monitoring functions
GUID-E3777F16-0B76-4157-A3BF-0B6B978863DE v15
IEC 61850 or
function name
ANSI Function description Line distance
REL650 (A11) REL650 (A12)
Control
SESRSYN 25 Synchrocheck, energizing check and synchronizing 1 1
SMBRREC 79 Autorecloser 1 1
QCBAY Bay control 1 1
LOCREM Handling of LR-switch positions 1 1
LOCREMCTRL LHMI control of PSTO 1 1
SXCBR Circuit breaker 3 3
SCILO Interlocking 1 1
SCSWI Switch controller 1 1
XLNPROXY Proxy for signals from switching device via GOOSE 3 3
SLGAPC Logic rotating switch for function selection and LHMI
presentation
15 15
VSGAPC Selector mini switch 30 30
DPGAPC Generic communication function for Double Point indication 16 16
SPC8GAPC Single point generic control function 8 signals 5 5
AUTOBITS Automation bits, command function for DNP3.0 3 3
SINGLECMD Single command, 16 signals 4 4
I103CMD Function commands for IEC 60870-5-103 1 1
I103GENCMD Function commands generic for IEC 60870-5-103 50 50
I103POSCMD IED commands with position and select for IEC 60870-5-103 50 50
I103POSCMDV IED direct commands with position for IEC 60870-5-503 50 50
I103IEDCMD IED commands for IEC 60870-5-103 1 1
I103USRCMD Function commands user defined for IEC 60870-5-103 4 4
Secondary system supervision
CCSSPVC 87 Current circuit supervison 1 1
FUFSPVC Fuse failure supervision 1 1
Logic
SMPPTRC 94 Tripping logic 6 6
SMAGAPC General start matrix block 6 6
STARTCOMB Start combinator 32 32
TMAGAPC Trip matrix logic 12 12
ALMCALH Logic for group alarm 5 5
WRNCALH Logic for group warning 5 5
INDCALH Logic for group indication 5 5
1MRK 506 384-BEN A
Line distance protection REL650 2.2
Product version: 2.2.1
ABB 9

ABB REL650 Specifications

General

Brand	ABB
Model	REL650
Category	Protection Device
Language	English
