3. Preconfigurations
The 630 series IEDs are offered with optional
factory-made preconfigurations for various
applications. The preconfigurations
contribute to faster commissioning and less
engineering of the IED. The
preconfigurations include default
functionality typically needed for a specific
application. Each preconfiguration is
adaptable using the Protection and Control
IED Manager PCM600. By adapting the
preconfiguration the IED can be configured
to suit the particular application.
The adaptation of the preconfiguration may
include adding or removing of protection,
control and other functions according to the
specific application, changing of the default
parameter settings, configuration of the
default alarms and event recorder settings
including the texts shown in the HMI,
configuration of the LEDs and function
buttons, and adaptation of the default single-
line diagram.
In addition, the adaptation of the
preconfiguration always includes
communication engineering to configure the
communication according to the functionality
of the IED. The communication engineering
is done using the communication
configuration function of PCM600.
If none of the offered
preconfigurations fulfill the
needs of the intended area of
application, 630 series IEDs
can also be ordered without
any preconfiguration. In this
case the IED needs to be
configured from the ground
up.
Table 1. REM630 preconfiguration ordering options
Description Preconfiguration
Preconfiguration A for asynchronous motor A
Preconfiguration B for asynchronous motor including
differential protection B
Number of instances available n
Motor Protection and Control 1MRS756977 D
REM630
Product version: 1.1 Issued: 2011-05-18
ABB 5
