Table 99. Test switch mounting accessories
Item Order number
19" rack mounting kit for one RTXP8 test switch (the test switch is
not included in the delivery)
1KHL400465R0001
19" rack mounting kit for one RTXP18 test switch (the test switch is
not included in the delivery)
1KHL400467R0001
19" rack mounting kit for one RTXP24 test switch (the test switch is
not included in the delivery)
1KHL400469R0001
Table 100. Connector sets
Item
Order number
Connector set for one 4U housing IED including analog input
variant 4I + 5U or 5I + 4U
2RCA021735
Connector set for one 6U housing IED including analog input
variant 4I + 5U or 5I + 4U
2RCA021736
Connector set for one 4U housing IED including analog input
variant 7I + 3U
2RCA023041
Connector set for one 6U housing IED including analog input
variant 7I + 3U
2RCA023042
Connector set for one 4U housing IED including analog input
variant 8I + 2U
2RCA023039
Connector set for one 6U housing IED including analog input
variant 8I + 2U
2RCA023040
Table 101. Optional cables for external display module
Items
Order number
LHMI cable (1m) 2RCA025073P0001
LHMI cable (2m) 2RCA025073P0002
LHMI cable (3m) 2RCA025073P0003
LHMI cable (4m) 2RCA025073P0004
LHMI cable (5m) 2RCA025073P0005
24. Tools
The IED is delivered either with or without
an optional factory made preconfiguration.
The default parameter setting values can be
changed from the front-panel user interface,
the web-browser based user interface
(WebHMI) or the PCM600 tool in
Motor Protection and Control 1MRS756977 D
REM630
Product version: 1.1 Issued: 2011-05-18
62 ABB
