ABB Relion 630 Series User Manual

Table 103. Supported functions
Function WebHMI PCM600 PCM600
Engineering
PCM600
Engineering
Pro
Parameter setting
● ● ● ●
Disturbance handling
● ● ● ●
Signal monitoring
● ● ● ●
Event viewer
● ● ● ●
Alarm LED viewing
● ● ● ●
Hardware configuration -
● ● ●
Signal matrix -
● ● ●
Graphical display editor -
● ● ●
IED configuration templates -
● ● ●
Communication management -
● ● ●
Disturbance record analysis -
● ● ●
IED user management -
● ● ●
User management -
● ● ●
Creating/handling projects -
● ● ●
Graphical application
configuration
- -
● ●
IEC 61850 communication
configuration, incl. GOOSE
- - -
●
25. Supported ABB
solutions
ABB’s 630 series protection and control IEDs
together with the COM600 Station
Automation device constitute a genuine IEC
61850 solution for reliable power distribution
in utility and industrial power systems. To
facilitate and streamline the system
engineering ABB’s IEDs are supplied with
Connectivity Packages containing a
compilation of software and IED-specific
information including single-line diagram
templates, manuals, a full IED data model
including event and parameter lists. By
utilizing the Connectivity Packages the IEDs
can be readily configured via the PCM600
Protection and Control IED Manager and
integrated with the COM600 Station
Automation device or the MicroSCADA Pro
network control and management system.
The 630 series IEDs offer support for the IEC
61850 standard also including horizontal
GOOSE messaging. Compared with
traditional hard-wired inter-device signaling,
peer-to-peer communication over a switched
Motor Protection and Control 1MRS756977 D
REM630
Product version: 1.1 Issued: 2011-05-18
64 ABB
