Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
2 Safety / 2.5 Warning plates on the turbocharger
© Copyright 2018 . All rights reserved. HZTL2481_EN Revision C May 2018
2.5 Warning plates on the turbocharger
Warning plates that must be observed are attached to the turbocharger.
The warning plates must always be present in the intended locations
and must be legible.
Part number Size [mm] Product
81080 105 x 74 TPL / TPR
When uninsulated turbochargers are delivered to the engine builder, the
warning plates must be subsequently attached to the insulation. This is
the responsibility of the engine builder.
Page 16 / 136
