ABB TPL69-A Series User Manual

Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
8 Disassembly and assembly / 8.6 Dismantling and installing the tur-
bine diffuser and nozzle ring
© Copyright 2018 . All rights reserved. HZTL2481_EN Revision C May 2018
8.6 Dismantling and installing the turbine diffuser
and nozzle ring
CAUTION
Falling nozzle ring
The nozzle ring hangs only loosely on the positioning pins.
u Before removing the turbine diffuser, secure the nozzle to prevent it
from falling.
u Before disassembling the turbine diffuser, if possible secure the
nozzle ring against falling with a lashing strap and a wooden block.
Page 96 / 136
