25
1ZSE 5492-118 en, Rev. 4
5 Final assembly
5. Final assembly
5.1 Mounting of the motor-drive mechanism
See gs. 1, 13 and 14.
Proceed as follows:
1. Mount the motor-drive mechanism onto the transformer.
The mounting holes on the transformer should be leveled within 1 mm. If adjustment is
needed, shims should be used.
2. Install the bevel gear on the edge of the transformer cover.
3. Check that the position indicator in the motor-drive mechanism shows the same posi-
tion as the indicator inside the top cover of the on-load tap-changer.
WARNING
Do not energize the transformer before the on-load tap-changer and motor-drive
mechanism are correctly assembled.
