Mechanical installation
Contents of this chapter
This chapter describes the installation procedures and the contents of the delivery.
Examining the delivery
Make sure that these items are included:
• control unit with the I/O connector plugs
• UMU-01 memory unit
• microSDHC flash memory card (inserted in its slot inside the UMU memory unit)
• BR2032 battery
• USCA-02 option slot adapters.
Make sure that there are no signs of damage to any of the items.
￭
Identifying different control unit types
Before you install the control unit, make sure that it has the correct control program
for the hardware in question. The control program is shown on the label attached to
the memory unit.
Make sure that the control unit is correct for your equipment configuration.
3
Mechanical installation 15
