8 Application of the X-ray regulations
One of the physical properties of vacuum insulation
is the possibility of X-ray emissions when the con-
tact gap is open. The specified test performed by
the Physikalisch-Technische Bundesanstalt (PTB)
in Braunschweig demonstrates that the local dos-
age output of 1 μSv/h at a distance of 10 cm from
the touchable surface is not exceeded when the
rated voltage is applied.
The results are as follows:
• Testing of the switching device or the vacuum
interrupter to VDE 0671 part 100 or IEC 62271-
100 at the relevant rated power frequency
withstand voltage may only be performed by
trained personnel observing the stipulations of
the EU basic standard (Directive 96/29/Euratom
of the Council of 13 May 1996 (ABI.L 159 of
29 June 1996)).
• Application of the rated power frequency with-
stand voltage specified for the switching device
by VDE 0671 part 100 or IEC 62271-100 is
completely safe.
• Higher voltages than the rated power frequency
withstand voltage or DC test voltage specified in
VDE or IEC standards must not be applied!
• The containment of the above mentioned local
dosage output with the vacuum interrupter in the
open position is dependent on maintenance of
the specified distance between the contacts
(which is automatically ensured with correct
mechanism function and force transmission).
• Safety clearances must be maintained.
9 Comparison of designations to VDE-DIN 40719 Part 2 and IEC 61346-1/IEC 61346-2
VDE IEC
DIN 40719 Part 2
Description
61346-1/61346-2
-S1 Auxiliary switch on operating mechanism -BS1
-S2 Auxiliary switch on blocking magnet -Y1 -BL1
-S3 Auxiliary switch on the breaker shaft -BB1
-S4 Auxiliary switch on the breaker shaft -BB2
-S5 Auxiliary switch on the breaker shaft -BB3
-S7 Auxillary switch for fault annunciation
Fleeting contact time ≥ 30 ms -BB4S
-Y1 Blocking magnet -RL1
-Y2 Shunt release OFF -MO1
-Y3 Shunt release ON -MC
-Y4 Undervoltage release -MU
-Y7 Indirect overcurrent release -MO3
-Y9 Second shunt release OFF -MO2S
-V1 Series rectifier for -Y1 -TR4
-V2 Series rectifier for -Y2 -TR1
-V3 Series rectifier for -Y3 and -K0 -TR3
-V4 Series rectifier for -Y4 -TR6
-V9 Series rectifier for -Y9 -TR2
-M0 Charging motor for spring energy store -MS
-K0 Antipumping relay -KN
-R0 Series resistor -RR
