Absen NX Series User Manual

NX Series Product User Manual
27
3.3 Wall mounting
3.3.1 Unlimited splicing horizontal and vertical bar installation
3.3.1.1 Installation accessories are as follows:
Type
Short name
Instructions for use
Big and small cabinets share
vertical bars
Single vertical bar
Used when the screen is arranged in
2 or 3 lines
Double vertical bar
Used when the screen is arranged in
4 lines or more
Big cabinet (960*540mm)
horizontal bar
horizontal bar
——
Big cabinet (960*540mm)
horizontal bar connector
connector
Connect the two vertical bar
Small cabinet (240*540mm)
horizontal bar
horizontal bar
——
Small cabinet (240*540mm)
horizontal bar connector
connector
Connect the two vertical bar
Wall connectors and required
screws
wall connector
1 single vertical bar with 1 wall
connector
Expansion bolt
1 wall connector with 3 expansion
bolts
T-bolts
1 wall connector with 3 T-bolts
Hex Flange Nuts
1 wall connector with 3 hex flange
nuts
Vertical bar right angle
connector
Vertical bar connector
1 vertical bars with 4 (regardless of
single and double)
hanging nails
hook up
1 horizontal bar with 2 hooks
