3.4 Trim pieces installation
This product supports trim pieces installation, and the trim pieces and the
cabinet are locked and fixed by external hexagonal combination machine screw
HM3*8.
3.4.1 The specification of the
trim pieces
name is as follows:
Trim pieces name
Trim pieces length
Remark
Upper and lower long trim pieces
(with chamfer)
960mm+trim pieces
thickness
Top left & bottom right
fixed position
Upper and lower standard trim
pieces
960mm
——
Left and right long trim pieces
(with chamfer)
540mm+trim pieces
thickness
Bottom left & top right
fixed position
Left and right standard single
trim pieces
540mm
——
Left and right standard double
trim pieces
1080mm
——
Upper and lower single-length
trim pieces (with chamfer), small
cabinet use
240mm+trim pieces
thickness
Top left & bottom right
fixed position
Upper and lower single trim
pieces, small cabinet use
240mm
——
Upper and lower double trim
pieces, small cabinet use
480mm
——
Required screws
External hexagon machine screw HM3*8 SUS304
3.4.2 Principles of the Trim pieces scheme:
1. The position of the upper left corner of the screen: the upper side is longer,
the left side is shorter;
2. The lower left corner position of the screen: the left side is longer and the
lower side is shorter;
3. The lower right corner position of the screen: the lower side is longer and
the right side is shorter;
4. The upper right corner position of the screen: the right side is longer and
