22
Terminal No. Symbol Function
36,37,38 VDD 5V POWER SUPPLY
1 TXE0- LVDS EVEN OUTPUT DATA PAIRS
2 TXE0+ LVDS EVEN OUTPUT DATA PAIRS
4 TXE1- LVDS EVEN OUTPUT DATA PAIRS
5 TXE1+ LVDS EVEN OUTPUT DATA PAIRS
7 TXE2- LVDS EVEN OUTPUT DATA PAIRS
8 TXE2+ LVDS EVEN OUTPUT DATA PAIRS
10 TXECLK- LVDS EVEN OUTPUT DATA PAIRS
11 TXECLK+ LVDS EVEN OUTPUT DATA PAIRS
13 TXE3- LVDS EVEN OUTPUT DATA PAIRS
14 TXE3+ LVDS EVEN OUTPUT DATA PAIRS
16 TXO0- LVDS ODD OUTPUT DATA PAIRS
17 TXO 0+ LVDS ODD OUTPUT DATA PAIRS
19 TXO1- LVDS ODD OUTPUT DATA PAIRS
20 TXO1+ LVDS ODD OUTPUT DATA PAIRS
22 TXO2- LVDS ODD OUTPUT DATA PAIRS
23 TXO2+ LVDS ODD OUTPUT DATA PAIRS
25 TXOCLK- LVDS ODD OUTPUT DATA PAIRS
26 TXOCLK+ LVDS ODD OUTPUT DATA PAIRS
28 TXO3- LVDS ODD OUTPUT DATA PAIRS
29 TXO3+ LVDS ODD OUTPUT DATA PAIRS
03,06,09, 12 GND Ground
15, 18, 21, 24 GND Ground
27, 30, 34, 35 GND Ground
39,40 GND Ground
3.6.3 J2
Pin NO. Signal Comment
1,2 5 VCC 5V Power Input
3,4,5 GND GND
6 BLON Bright Light ON/OFF.
7 BRIGHT Brightness Adjustment.
