Machine Maintenance Procedures 3-41
Bluetooth Module Removal 0
Prerequisite:
Upper Cover Removal
1. Locate Bluetooth module (A) on lower cover. (Figure 3-45)
Figure 3-45. Lower Cover Overview
2. Remove Bluetooth module and adhesive from lower cover.
3. Disconnect Bluetooth cable (D) from Bluetooth module connector. (Figure 3-46)
Figure 3-46. Bluetooth Module
4. Remove adhesive (E) from Bluetooth module.
