Hardware Specifications and Configurations 1-19
Right View 0
Figure 1-6. Right View
Table 1-8. Right View
No Icon Item Description
1 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB mouse,
USB camera).
2 Optical drive Internal optical drive; accepts CDs or DVDs.
3 Optical drive eject
button/optical disk
access indicator
Ejects the optical disk from the drive and lights up
when the optical drive is active.
4 Emergency eject hole Ejects the optical drive tray when the computer is
turned off.
Insert a tool into the emergency eject hole to
eject the optical drive tray when the computer
is off.
5 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based
network.
6 Kensington lock slot Connects to a Kensington-compatible computer
security lock.
Wrap the computer security lock cable around
an immovable object such as a table or handle
of a locked drawer. Insert the lock into the
notch and turn the key to secure the lock.
Some keyless models are also available.
