28 Chapter 3

Removing the Side Panel

1. Perform the pre-disassembly procedure described on page 24.

2. Remove the two screws (A) located on the side panel.

3. Slide the side panel toward the back of the chassis until the tabs on the cover disengage with the slots on

the chassis.

4. Lift the side panel away from the server and put it aside for reinstallation later.

Screw (Quantity) Color Torque Part No.

#6-32 L5 BZN (2) Black 5.5 to 6.5 kgf-cm 86.00J07.B60

X1700 model X270 model
