Acer PD1330W Series User Manual

3
English
Projector Overview
Projector Outlook
Front/upper side
Rear side
# Description # Description
1Vents 5Indicator LED
2 Zoom ring and Focus ring 6 Remote control receiver
3 Security slot 7 Projection lens
4 Control panel
# Description # Description
1 LAN (RJ45 port for 10/100M
Ethernet)
6 DC 5V output (service)
2 Audio input connector
Audio output connector
7 RS232 connector
3 USB connector (Type A) 8 Power socket
4 HDMI connector 9 Kensington™ lock port
5 Analog RGB signal/HDTV/
component video input connector
10 Tilt adjusting wheel
1
3
2
6
7
5
1
4
10 10
9
8
1 2 3 6754
Note: Connector interface is subject to model's specifications.

Acer PD1330W Series Specifications

General

Brand	Acer
Model	PD1330W Series
Category	Projector
Language	English
