21 Chapter 3
Mechanical Disassembly & Reassembly
This section provides disassembly & Reassembly procedures for PD726 & PH730 DMD
Projector. Before you begin any of these procedures, be sure to turn off the power, computer
system, and other attached devices; then disconnect the power cable from the electrical
outlet. Moreover, when you disassemble the projector, be sure to put the screws in a safe
place and separate them according to their category.
Equipment Needed
Chapter 3
General Information
Before You Begin
Before proceeding with the disassembly procedure, make sure that you do the following
procedures:
1. Turn off the power of the system and all the peripherals.
2. Unplug the AC adapter and all power and signal cables from the system.
3. Anti-static wrist strap.
Item Photo Item Photo
Philips (+) : 107 Philips (+) : 102
Philips (+) : 101
Hex Screw :
5mm
Screw Bit :
6.0 X 100
Side Cutter
Pliers
Long Nose
Pliers
Tweezers
Hexagon Keys
To Next Page
