Acer X110 User Manual

X1161/X1261/X1161A/X1161N/X110/H5360
Condential
iii
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-5
Product Overview 1-9
Chapter 2 Disassembly Process & Assembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Top Shielding 2-3
Disassemble Front Cover and IR Sensor Board 2-4
Disassemble Main Board Module and IO Cover Module 2-5
Disassemble Engine Module 2-7
Disassemble Color Wheel Module 2-8
Disassemble DMD Chip and DMD Board 2-8
Disassemble Zoom Ring 2-9
Disassemble Focus Ring 2-9
Disassemble System Fan Module 2-10
Disassemble Blower 2-11
Disassemble LVPS Module 2-11
Disassemble Lamp Driver Module 2-12
Disassemble Interrupt Switch 2-13
Disassemble Bottom Shielding 2-13
Disassemble Speaker (for X1261/H5360) 2-14
Rod Adjustment 2-14
Re-write System and Lamp Usage Hour 2-15
Assemble Speaker (for X1261/H5360) 2-16

Acer X110 Specifications

General

Display Technology	DLP
Resolution	SVGA (800 x 600)
Contrast Ratio	4000:1
Weight	2.2 kg
Brightness	2500 ANSI lumens
Lamp Life	6000 hours (Eco)
