Acer X193HQ Service Manual

- 11 -
3.3.4 Environment
Item Condition Spec OK N.
A
Remark
Operating
0 ~ +40 ℃
√
Temperature
Non-operating
-20 ~ +60 ℃
√
Operating 10 ~ 90%
√
Non-
condensing
Humidity
Non-operating 10 ~ 90%
√
Non-
condensing
Operating 12,000(ft)
√
at 25°C (hold
3.5 hrs)
Altitude
Non-operating 40,000(ft)
√
at -30 °C (hold
1 hr)
3.3.5 Transportation
Item Condition Spec OK N.
A
Remark
(1) Vibration Package, Non-Operating
Test Specification:
1. Frequency Hertz 5 ~
250 HZ , PSD Level
0.0054 (G2/Hz)
2. Grms = 1.146
3. Sweep Time : 30
minutes per Axis
4. Axes : X,Y,Z
√
(2) Unpackaged Vibration
Unpackaged, Non-
Operating
Test Spectrum:
20 Hz 0.0185(g2/Hz)
200Hz 0.0185(g2/Hz)
Duration
: 5 Minutes
Axis : 3 axis
( Horizontal and Vertical
axis ,Z axis)
(3) Drop Package, Non-Operating
76 cm Height (MP stage)
(1 corner, 3 edges, 6
faces)
√
(4) Shock
Wooden package, Non-
Operating
1. Amplitude : Half sine-
wave 50G
2. Duration : 10 ms
3. Test Times : 1
4.Test Sides : All 6 Sides
√
3.3.6 Electrostatic Discharge Requirements
Item Condition Spec OK N.
A
Remark
Electrostatic Discharge IEC801-2 standard
Contact: 8KV
Air: 15KV
√

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
