Acer X193HQ Service Manual

- 6 -
Auto adjustment function supported Yes “Auto-Key” function
DDC function supported (EDID ver. 1.3) Yes DDC2B
DDC-CI support version 1.1 or later Yes DDC-CI
Audio speakers supported No
Audio Jack (input connector) supported No
Earphone Jack (input connector)
supported
No
Microphone function supported No
Mechanical Tilt base design Yes From -5 to +23 degree
VESA wall mounting design Yes
Mechanical Rotate design No
Mechanical Lift base design No
Kensington compatible lock design Yes
3.2. Operational Specification
3.2.1 Power supply
Item Condition Spec OK N.A Remark
Input Voltage range
Universal input full
range
90~264VAC /47~63Hz
√
Input Current range 90 ~ 264VAC ≤ 2.0 Arms
√
Power Consumption Normal “On” operation ≤30 W
√
LED: Blue
DPMS DPMS “Sleep” state ≤ 2 W
√
LED: Amber
DPMS DPMS “Off” state ≤ 1 W
√
LED: OFF
Inrush Current
110 VAC
220 VAC
< 30 A (peak)
< 60 A (peak)
√
Cold-start
Earth Leakage Current 264 VAC/50Hz < 3.5 mA
√
Hi-Pot
1. 1500VAC, 1 sec
2. Ground test: 30A,
1sec
Without damage
< 0.1 ohm
√
(on-line test)
(in-lab test)
Power Line Transient IEC1000-4-4 1KV
√
IEC1000-4-5 (Surge)
Common: 2KV,
Differential: 1KV
√
CCFL operation range 90 ~ 264VAC 3~8mA
√
Depends on panel
source
CCFL Frequency 90 ~ 264VAC 40KHz ~ 80KHz
√
Depends on panel
source
Power cord
Color: Black
Length: 1800 +/- 50
mm
√

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
