Acer X193HQ Service Manual

- 15 -
3.6. Mechanical Characteristics
3.6.1 Dimension
Item Condition Spec OK N.A Remark
Bezel opening
411.7*232.3 mm
√
Monitor without Stand W x H x D mm
456.41*280.56*68.46m
m
√
Monitor with Stand W x H x D mm
456.41*334.54*163.72m
m
√
Carton Box (outside) L x W x H mm
504*126*394mm
√
Tilt and Swivel range
Tilt: -5 ~ +15 degree
Swivel: 0 degree
√
3.6.2 Weight
Item Condition Spec OK N.A Remark
Monitor (Net)
3.56Kg
√
Monitor with packing
(Gross)
4.22Kg
√
3.6.3 Plastic
Item Condition Spec OK N.A Remark
Flammability
>ABS<,94-HB
√
Heat deflection To
ABS
65
℃
√
UV stability
ABS Delta E < 8.0
√
Resin
BEZEL: PMMA+ABS
UC,BASE:ABS
(Bezel:Cheil/BF
-0677F,
LG/XG586,BASF/
BX13036)
Other:
HF380/SD0150)
√
Texture
UC:AT-IM-D02;
Bezel: AT-IM-D01
√
Color
BEZEL : DB19A;
UC: DB19A
√
3.6.4 Carton
Item Condition Spec OK N.A Remark
Color
Kraft
√
Material
B Flute
√
Compression strength
200KGF
√
Burst Strength
16 KGF/cm
2
√
Stacked quantity
4 Layers Vertical +2
layers H
√

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
