Acer X193HQ Service Manual

- 49 -
6.3 Spare Parts List
Ship To Area Part Number Description
EMEA ET.LEK0D.002
18.5W LCD MNT DUAL EU
LEVEL CATEGORY DESCRIPTION OEM PART NO.
1 LCD
LCDM18.5W M185XW01-V0 Z AUO 5F.LUHV0.001
1
BOARD
PCBA CTRL BD MI P22XW 5E.0GT03.001
1
BOARD
PCBA IFBD DUAL AU MI X193HQ 5E.0NA01.004
1
BOARD
PCBA SPS BD MI X193HQ 5E.0NA02.001
1
CABLE
CORD H05VV-F 10A250V EUR 1.8M 2G.00921.001
1
CABLE
CABLE DVI-D/DVI-D 1.8M IS_8 VW 5K.05406.501
1 CABLE
WIRE 7/9P CTRL BD X193HQ 5K.0NA01.001
1 CABLE
WIRE LVDS 30/20P 1571 G900HD 5K.0NJ01.001
1
CABLE
WIRE PWR 10/11P 1571#28 G900H 5K.0NJ02.001
1
CABLE
CABLE SIGNAL/C H+V OD_5.5 1.8M 5K.L2H06.511
1
CASE/COVER/BRACKET
ASSEMBLY
ASSY BASE W/P DUAL X193W 6K.0K406.001
1
CASE/COVER/BRACKET
ASSEMBLY
ASSY BZL DB19A X193HQ 6K.0NA01.001
1
CASE/COVER/BRACKET
ASSEMBLY
ASSY RC DUAL X193HQ 6K.0NA03.001
1
CASE/COVER/BRACKET
ASSEMBLY
ASSY CLMN X193HQ 6K.0NA10.001

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
