2.1.5. Setup
Menu Structure - Setup
Display Functions Description
[-] External Alarm Only applicable if external alarm is connected
Stop Alarm Stop alarm
Test Alarm Includes testing red LED on front
Alarm time-out: 009 s
Amount of time the alarm is active in seconds. If value is set to 0,
alarm time-out is disabled and the alarm will be active until the fail-
ure that has triggered the alarm is corrected or the alarm has been
stopped. See above.
Alarm state: Disabled
[-] Setup details
Language: English
The language in the display; changing the display language does
not affect country setting
[-] Inverter details
Inverter name:
AEG PS The inverter's name. Max. 15 characters and not only numbers.
Group name:
*
The name of the group the inverter is part of
Group name Max. 15 characters
[-] Master mode
*
Master mode: Enabled
*
[-] Network
*
Only visible if Master mode is enabled.
[-] Initiate network scan
[-] Scan progress: 0%
[-] Inverters found: 0
Plant name:
*
The name of the plant.
Plant name
*
Max. 15 characters
[-] Set date and time
Date: dd.mm.yyyy (30.12.2002) Set the current date
Time: hh.mm.ss (13.45.27) Set the current time
[-] Calibration Only applicable if sensors are connected
[-] PV array
PV input 1: 6000 W
PV 1 area: 123 m
2
PV input 2: 6000 W
PV 2 area: 123 m
2
PV input 3: 6000 W Not visible if inverter only has 2 PV inputs
PV 3 area: 123 m
2
Not visible if inverter only has 2 PV inputs
[-] Irradiation sensor
Scale (mV/1000 W/m
2
): 75
Sensor calibration
Temp. coeff: 0.06 %/
o
C
Sensor calibration
[-] Temp. sensor offset
PV module temp: 2
o
C
Sensor calibration (offset)
Ambient Temp: 2
o
C
Sensor calibration (offset)
[-] S0 sensor input
Scale (pulses/kWh): 1000 Sensor calibration. See note
[-] Environment
CO
2
emission factor:
*
Value to be used for total CO
2
saved calculation
0.5 kg/kWh
*
Remuneration per kWh:
*
Value to be used for total revenue calculation
44.42 ct/kWh
Yield start count: 1000 kWh
*
A value used as an offset from the current production value when
calculating the yield.
[-] Communication setup Only applicable if communication accessories are connected
[-] RS485 setup
Network: 15
Subnet:15
Address: 255
[-] IP Setup
IP config: Automatic
IP address:
192.168.1.191
Subnet mask:
255.255.255.0
Default gateway:
192.168.1.1
DNS server:
123.123.123.123
Table 2.7: Setup
*) Not available.
2. Display
10 8000038784_00_BAL_en / L00410565-01_02
