AL-KO Robolinho 300 User Manual

GB
38 Robolinho
Product description
2 PRODUCT DESCRIPTION
This document describes a fully automatic, bat-
tery operated automatic lawn mower which
moves freely on a grass surface. The cutting
height can be adjusted.
2.1 Scope of supply (01)
The items listed here are included in the standard
scope of supply. Check that all items are included:
No. Component
1 Automatic lawn mower
2 Quick-start guide
3 Operating instructions
4 Lawn pegs *
5 Power supply
6 Base station incl. screw nails (5pcs.)
7 Boundary cable *
8 Winter cover *
* model-dependent (see technical data)
2.2 Automatic lawn mower (02)
No. Component
1 Control panel with display (interior)
2 STOP key (stops the appliance immedi-
ately and the cutting blade within 2s)
3 Charging contacts
4 Height adjustment (interior)
5 Front rollers (steering)
6 Mower deck
7 Drive wheel
8 Blade plate
9 Fastening screw
10 Clearer blade
11 Cutting blade
12 Rechargeable battery compartment
2.3 Symbols on the appliance
Symbol Meaning
Keep other people out of the danger
area!
Pay special attention when handling
this product!
Keep your hands and feet away
from the blade system!
Maintain a safety distance!
Read the operating instructions be-
fore starting operation!
Enter the PIN in order to start the
appliance!
Do not ride on the appliance!

AL-KO Robolinho 300 Specifications

General

Type	Robotic lawn mower
Noise level	60 dB
Cutting width	200 mm
Product color	Black, White
Rotational speed	3400 RPM
Maximum lawn area	300 m²
Maximum cutting height	55 mm
Minimum cutting height	25 mm
International Protection (IP) code	IPX1
Power source	Battery
Battery voltage	18 V
Battery capacity	2.2 Ah
Battery life (max)	45 min

Weight and Dimensions

Depth	400 mm
Width	600 mm
Height	290 mm
Weight	7000 g
Package weight	13000 g
