Emptying the collecting bag
The collecting bag has a fill level indicator 14 . The fill level indicator rises when the
motor is running and the collecting bag is empty. Once the collecting bag is full, the
fill level indicator rests again on the collecting bag. Empty the collecting bag.
If cuttings remain on the ground, empty the collecting bag as well.
1. Stop the motor and wait until the blade stands still.
2. Lift the discharge flap
13
until the collecting bag
5
is exposed.
3. Lift the collecting bag 5 off the lawn mower.
Slightly lift the collecting bag to release it.
4. Move the discharge flap 13 properly until the discharge chute is covered again.
Do not simply let go; the discharge flap may get damaged due to the spring
action.
5. Empty the collecting bag 5 completely.
Clear cuttings of the fabric as best as possible so that the expelled air can escape
properly.
6. Completely lift the discharge flap 13 .
7. Hang the collecting bag
5 onto the hooks above the discharge chute again.
8. Check whether the collecting bag is properly fitted 5 .
9. Move the discharge flap 13 carefully until the collecting bag 5 is covered
again.
Cleaning
WARNING!
Risk of electric shock!
Moisture in the device may cause a short circuit or electric shock.
- Before cleaning, disconnect the power cable from the socket.
- Make sure that no water or other liquid gets inside the
housing.
- Never clean the device with running water (e.g. a garden
hose).
Operation
15
