User's Guide Memory
Chapter 3 - Memory
Your notebook is equipped with a configurable memory unit. The industry standard
JEDEC PC3200 (DDR-400) S.O.DIMM memory module sockets are available for
memory upgrade to 2048MB. The table below illustrates all the possible ways system
memory can be configured.
Total Memory Socket#1 Socket#2
256MB 0MB 256MB
256MB 256MB 0MB
512MB 0MB 512MB
512MB 256MB 256MB
512MB 512MB 0MB
768MB 256MB 512MB
768MB 512MB 256MB
1024MB 0MB 1024MB
1024MB 512MB 512MB
1024MB 1024MB 0MB
1280MB 256MB 1024MB
1280MB 1024MB 256MB
1536MB 512MB 1024MB
1536MB 1024MB 512MB
2048MB 1024MB 1024MB
Groove for indicating the
orientation of the module
DDR S.O. DIMM Memory Module
1.25” max
Page 3-1
