Memory User's Guide
3.1 Removing Memory Modules
Below is the procedure on how to remove the memory modules.
• Make sure the system is properly
shutdown.
• Flip the system upside down as
shown.
• Remove the battery pack as shown in
Chapter 2.
• Remove the four screws as shown by
#1.
• Remove the compartment door as
shown by #2.
Memory Modules
• Press the spring-locks sideways as
shown by #1.
• The first memory module will pop up
as shown by #2.
• Remove the first memory module as
shown by #3.
Page 3-2
