ALLEN&HEATH 21 AP11645_1_XONE:96 User Guide
REAR PANEL CONNECTORS
1
X:Link
Connect XONE:K Series Controllers to the XONE:96 mixer for remote software MIDI control and to save
using USB ports on your computer.
RJ-45, Ethernet.
3
USB 1 and USB 2 Soundcards
Dual 24 Channel (6 Stereo IN/6 Stereo OUT), 32Bit/96kHz, internal Hi-Speed USB soundcards. macOS
class compliant. ASIO* compatible. Direct, full-duplex, USB 1/USB 2 MIDI connection. See p.23-36.
USB-B.
4
RECORD Outputs
Pre-MASTER (MST) level, LR MIX output for connection to external hardware recording devices
Unbalanced RCA.
2
MIDI OUT
MIDI signal output from XONE:96, USB 1, USB 2, or X:LINK for syncing to external MIDI hardware.
5-pin DIN.
6
PHONO Inputs, CH 1 - 4
Connect turntables with magnetic cartridges requiring RIAA equalisation to PHONO inputs.
For non-RIAA turntables plug into the LINE input instead.
Unbalanced RCA.
8
USB LINE / PHONO Select Switches, CH 1 - 4
Set CH1 - 4 USB 1 and USB 2 sources to LN or PH for LINE or RIAA signal level input to internal
soundcards. For DVS (CD/Vinyl timecode) control, or recording CH1 - 4 inputs via USB 1 or USB 2.
5
Chassis Earth Terminals
2 screw terminals are provided for connecting the earth straps from turntables to prevent ground hum.
7
LINE Inputs, CH 1 - 4
Connect stereo LINE level media players to the LINE inputs. Do not connect turntables requiring RIAA
equalisation. You can also connect to LINE level jack sources using RCA to jack adapter/cables.
Unbalanced RCA.
9
Audio Sync Out
Enables future ALLEN&HEATH accessories to be easily connected to the XONE:96.
Alternative secondary Record Out; pre-MASTER level, LR MIX output to external devices.
Stereo 3.5mm mini-jack.
Total Connectivity
XONE:96’s rear panel is fully-loaded with I/O. Alongside all the analogue connections you’d expect to find, DJs
will welcome the addition of dual-soundcards, 2 stereo sends, 4 stereo returns and dedicated master insert.
SND/RTN A is switchable between Line and Hi-Z levels, making it ideal for incorporating instrument level effects,
like classic guitar pedals, or legacy outboard hardware.
X-Link allows you to hook up XONE:K series controllers to the XONE:96 for hands-on control over your
software, saving USB ports on your laptop.
MIDI Output to external hardware is catered for via the 5-pin connection on the rear panel, and to computers via
USB 1 and USB 2 ports.
*ASIO is a trademark and software of Steinberg Media Technologies GmbH
