ALLEN & HEATH XONE:96 User Manual

ALLEN&HEATH 35 AP11645_1_XONE:96 User Guide
TECHNICAL SPECIFICATIONS
Hardware Specification
Output Levels; Nom (0VU) / Max MASTER 1 + 4dBu / + 24dBu
INSERT - 2dBu
MASTER 2 + 4dBu / + 18dBu
BOOTH + 4dBu / + 18dBu
RECORD - 8dBu / + 10dBu
Internal headroom Channels + 20dB
Frequency response LINE IN to MST out +/-0.5dB from 20Hz to 30kHz
Distortion Typically 0.03% @ 1kHz 0dBu (THD+Noise 22Hz to 22kHz)
Crosstalk < -85dB inter-channel @ 1kHz +10dBu
Residual Noise (22Hz - 22kHz) MASTER 1 - 98dBu
MASTER 2 - 98dBu
BOOTH -101dBu
Mix Noise (22Hz - 22kHz) Master 1 - 90dBu
Master 2 - 85dBu
Booth - 85dBu
Record RCA - 90dBu
Mic Gain +40dB, EIN = -120dB (@ 40dB gain with 150R source)
RIAA Gain +42dB @ 1kHz (6mV RMS= 0VU @ 1kHz)
Channel Meters 9 LED - 20dBu to + 10dBu
Master Meters 11 LED - 35dBu to + 10dBu
Channel EQ A/B HI 3kHz + 6/-∞dB
PARAMETRIC 190Hz - 2.75kHz +10/-24dB
LO 180Hz + 6/-∞dB
Channel EQ 1-4 HI 3kHz + 6/-∞dB
HI MID 1.1kHz +10/-27dB
LO MID 350Hz +10/-27dB
LO 180Hz + 6/-∞dB
Channel faders 1-4 60mm VCA control individually replaceable.
Plug in replacement - user replaceable [A&H spare-part#: AI11470]
< -85dB shutoff @1kHz +10dBu
Cross-fader 45mm innoFADER VCA control.
Plug in replacement - user replaceable [A&H spare-part#: 004-999X]
Filters Dual, stereo, analogue Voltage Controlled Filters.
Digital Architecture (USB) Specification
Analogue/Digital Line-up 0dBu = - 14dBFS
Audio Channels: 24 Channel (6 Stereo IN / 6 Stereo OUT),
Supported Variable Buffer Sizes: 32 / 64 / 128 / 256 / 512 / 1024 / 2048 / 4096 / 8192 samples
Supported Sample Rates: 44.1 kHz / 48kHz / 88.2kHz / 96kHz
Supported Bit depth: 16 bit / 32 bit
USB MIDI Channels: 2 x MIDI IN / 2 x MIDI OUT (USB 1 and USB 2)

ALLEN & HEATH XONE:96 Specifications

General

Channels quantity	8 channels
Digital sound processing	- bit
Equalizer bands quantity	4
DJ mixer	-
Product color	Black, Grey
USB connector type	USB Type-B
Master (XLR) out	1
Headphone connectivity	3.5 mm/6.35 mm
Number of microphone inputs	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	45 W
Built-in display	No

Weight and Dimensions

Depth	410 mm
Width	336 mm
Height	109 mm
Weight	7000 g
