Parameter List/Record A-3
Parameter Record
Table A.B Fast Source Parameter List
Parameter
Number Description Default Value
Linked To
Parameter
1 TREND 1 OUTPUT
2 TREND 2 OUTPUT
3 TREND 3 OUTPUT
4 TREND 4 OUTPUT
10 SP OUTPUT 1
11 SP OUTPUT 2
12 SP OUTPUT 3
13 SP OUTPUT 4
14 SP OUTPUT 5
50 TREND 1 INPUT
51 TREND 2 INPUT
52 TREND 3 INPUT
53 TREND 4 INPUT
100 LOGIC STATUS
BIT 0 = FAULT FIELD 0
BIT 1 = FAULT FIELD 1
BIT 2 = ACTIVE LOGIC COMMAND 0
BIT 3 = ACTIVE LOGIC COMMAND 1
BIT 4 = CONTACTOR CLOSE
BIT 5 = DRIVE RUNNING
BIT 6 = RUNNING REVERSE
BIT 7 = READY
BIT 8 = AT CURRENT LIMIT
BIT 9 = SET SPEED
BIT 10 = AT ZERO SPEED
BIT 11 = AT SPEED 1
BIT 12 = AT SPEED 2
BIT 13 = AT SPEED 3
BIT 14 = AT SPEED 4
BIT 15 = AT SPEED 5
101 DRIVE FAULT
102 PRE RAMP VELOCITY REFERENCE
103 RAMP VELOCITY REFERENCE
104 FINAL VELOCITY REFERENCE
105 ARMATURE VOLTAGE FEEDBACK
106 VELOCITY FEEDBACK
107 POSITION FEEDBACK
108 VELOCITY FEED FORWARD
109 POSITION ERROR
110 TORQUE COMMAND
111 ARMATURE CURRENT REFERENCE
112 ARMATURE CURRENT FEEDBACK
113 ARMATURE CURRENT PI OUTPUT
114 ARMATURE CURRENT FIRING ANGLE
115 FLUX COMMAND
116 AC LINE COMMAND
117 FIELD CURRENT REFERENCE
118 FIELD CURRENT FEEDBACK
119 PROCESS TRIM OUTPUT
