12 Universal Serial Bus (USB) to DH-485 Interface Converter
Publication 1747-IN063C-EN-P - January 2006
3. Choose RS-232 DF1 devices from the Available Driver Types pulldown menu
and click Add New…
4. Enter a name for your new driver and click OK.
5. Choose the COM Port to which the interface converter is associated, in this
case COM 3.
6. Choose 1770-KF3/1747-KE as the Device.
7. Set Error Checking to CRC. The default is BCC.
TIP
You can determine the COM port to which the interface
converter is assigned using the Device Manager.
See Identify the Assigned COM Port on page 11.
