Allen-Bradley 1756 Series User Manual

Rockwell Automation Publication 1756-UM013B-EN-P - October 2019 53
1756-IB16S Input Module Features Chapter 3
Point Diagnostics
Point diagnostics provide information on an individual point basis. For example,
you can check individual input points and test output points on a 1756-IB16S
safety input module for the presence of a Short Circuit condition.
Figure 12
shows how to access output point diagnostics on the 1756-IB16S
module and the diagnostics dialog box.
Figure 12 - Point Diagnostics
