Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 303
Use a Secure Digital Card Chapter 12
6. Click Load.
A dialog box prompts you to confirm the load.
7. To load the project, click Yes.
8. Click OK.
After you click Load, the project is loaded into the controller as indicated by the
controller status indicators. These conditions can exist:
• While the load is in progress, the following occurs:
– The controller resets itself.
When the controller is resetting itself, the status indicators execute a
sequence of state changes, for example, a brief time with the OK status
indicator in the solid red state. Wait for the controller to complete the
sequence.
– After the controller fully resets itself, the OK indicator is solid green.
– The SD indicator is off.
Project that is currently on the memory card of the
controller (if any project is there).
Project that is currently in the user memory of
the controller.
To Next Page
