Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 37
Install the CompactLogix 5370 L2 Controller Chapter 2
CompactLogix 5370 L2 Controller Parts
These parts are included in the box when you order your controller:
• Controller - Specific catalog number varies by order
• 1769-ECR Compact I/O end cap/terminator
• 1784-SD1 Secure Digital (SD) card with 1 GB of memory storage
A 1784-SD2 SD card with 2 GB of memory storage, or more1784-SD1
SD cards, are also available if you need extra memory.
Installation Summary
To install a CompactLogix 5370 L2 controller, follow these steps.
1. Install the Secure Digital Card
.
2. Install the System
.
3. Connect to the Controller via a USB Cable
.
4. Connect the Controller to an EtherNet/IP Network
.
ATTENTION: CompactLogix 5370 L2 control systems do not support
removal and insertion under power (RIUP). Removing a 1769 Compact
I/O module or end cap generates a controller fault and may also result in
damage to system components.
The life expectancy of nonvolatile media is dependent on the number
of write cycles that are performed. Nonvolatile media use a wear
leveling technique or technology for prolonging the service life, but
avoid frequent writes.
Avoid frequent writes when logging data. We recommend that you log
data to a buffer in the memory of your controller and limit the number
of times data is written to removable media.
