Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 75
Chapter 4
Complete Software Tasks Required at
CompactLogix 5370 Controller Installation
To complete the tasks that are described in this chapter, you must have the
software that is described in the following table installed on your computer.
CompactLogix 5370 controllers require a network Internet Protocol (IP) address
to operate on an EtherNet/IP network.
Topic Page
Set the IP Address of a Controller 77
Change the IP Address of a Controller 94
Load the Controller Firmware 98
Select the Operating Mode of the Controller 112
Software Required Version
RSLinx

Classic 2.59.00 or later
CompactLogix 5370 L2 controllers require RSLinx Classic software,
version 2.59.01 or later.
The1769-L19ER-BB1B controller requires RSLinx Classic software,
version 3.74.00
RSLogix 5000® 20 - For CompactLogix 5370 controllers using firmware revision 20.
RSLogix 5000 software does not support the 1769-L19ER-BB1B
controller.
Studio 5000® environment 21 or later - For CompactLogix™ 5370 controllers using firmware
revision 21 or later.
28 or later - For the 1769-L19ER-BB1B controller.
BOOTP-DHCP server Most current version is installed with RSLinx Classic software installation
ControlFLASHâ„¢ Installed with the installation of one of the following:
• RSLogix 5000 software, version 20
• Studio 5000 environment, version 21 or later
• Studio 5000 environment, version 28 or later for 1769-L19ER-BB1B
controllers
