Rockwell Automation Publication 2711P-IN001J-EN-P - April 2018 21
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
AC Power Connections
PanelView Plus devices with an integrated AC power supply have these power ratings:
• 85…264V AC (47…63 Hz)
•160V A max
The input power terminal block supports these wire sizes.
Protective Earth and Functional Earth Connection
PanelView Plus devices with an AC power input have both a protective earth and functional
earth terminal that you must connect to a low-impedance earth ground.
• Protective earth terminal is on the power input terminal block.
• Functional earth connection is on the back of the display.
The protective earth and functional earth terminals require a minimum wire gauge.
Wire Specifications for AC Input Power Terminal Block
Wire Type
Dual-wire
Gauge
(1)
(1) Two-wire max. per terminal.
Single-wire
Gauge
Terminal Screw Torque
Stranded or solid Cu 90 °C (194 °F) 22…16 AWG 22…14 AWG 0.56 N•m (5 lb•in)
The functional earth and protective earth connections to ground are mandatory. The
functional earth ground connection is required for electromagnetic compliance (EMC) with
the EU (European Union) EMC directive for CE-mark conformance. The protective earth ground
connection is required for safety and regulatory compliance.
IMPORTANT On PanelView Plus devices with an AC power input, you must connect both protective earth
and functional earth to ground.
Functional Earth and Protective Earth Wire Specifications for AC Power
Connection Wire Type Wire Gauge
Terminal Screw
Torque
Protective earth Stranded or solid Cu 90 °C (194 °F) 14…12 AWG 0.56 N•m (5 lb•in)
Functional earth GND Stranded or solid Cu 90 °C (194 °F) 14…10 AWG
1.13… 1.36 N•m
(10…12 lb•in)
