Allen-Bradley PanelView Plus 700 Installation Instructions

Rockwell Automation Publication 2711P-IN001J-EN-P - April 2018 29
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
Specifications
PanelView Plus Terminals - 2711P-Kxxxx, 2711P-Txxxx, 2711P-Bxxxx, 2711P-RDxxxx, 2711PC-
Txxxx
Attribute Value
Display
Display type
Color active matrix, thin film transistor (TFT), liquid crystal display
(LCD)
Display size
700
1000
1250
1500
6.5 in.
10.4 in.
12.1 in.
15 in.
Display area (WxH)
700
1000
1250
1500
132 x 99 mm (5.2 x 3.9 in.)
211 x 158 mm (8.3 x 6.2 in.)
246 x 184 mm (9.7 in x 7.2 in.)
304 x 228 mm (12.0 x 9.0 in.)
Display resolution
700
1000
1250
1500
640 x 480
640 x 480
800 x 600
1024 x 768
Luminance 300 cd/m
2
Nits
Touch screen Analog resistive
Electrical
Input voltage, DC 24V DC nom (18…32V DC)
Power consumption, DC 70 W max (2.9 A @ 24V DC) 39 W typical (1.6 A @ 24V DC)
Input voltage, AC 85…264V AC (47…63 Hz)
Power consumption, AC 160VA max (65VA typical)
PCI slot max. available power
(1)
Supply, DC
Supply, AC
(1) The PCI slot does not apply to the PanelView Plus Compact 1000 terminal.
11 W
5 W
Dimensions, Approx, (HxWxD) for based configured unit without communication module
700 keypad, or keypad and touch 193 x 290 x 55 mm (7.58 x 11.40 x 2.18 in.)
700 touch 179 x 246 x 55 mm (7.04 x 9.68 x 2.18 in.)
1000 keypad, or keypad and touch 248 x 399 x 55 mm (9.77 x 15.72 x 2.18 in.)
1000 touch 248 x 329 x 55 mm (9.77 x 12.97 x 2.18 in.)
1250 keypad, or keypad and touch 282 x 416 x 55 mm (11.12 x 16.36 x 2.18 in.)
1250 touch 282 x 363 x 55 mm (11.12 x 14.30 x 2.18 in.)
1500 keypad, or keypad and touch 330 x 469 x 65 mm (12.97 x 18.46 x 2.55 in.)
1500 touch 330 x 416 x 65 mm ((12.97 x 16.37 x 2.55 in.)
