Alpine CDE-143BT User Manual

20-EN
*10 FW VERSION can be selected in this mode. You can see the
current firmware version about BLUETOOTH by using this
setting.
*11 AUX NAME can be selected in this mode. For details, refer to
“Setting the AUX NAME mode” on page 21.
*12 CALL SOUND, CALLER ID, PB UPDATE, PB ORDER,
AUTO ANS, SPEAKER SL and FW VERSION can be
selected in this mode. For details about these settings, refer to
“BLUETOOTH SETUP” on page 23.
*13 The Hands free phone talk level, ring tone level and
microphone gain level can be adjusted by using this setting.
Changing the settings in the Option mode will also affect the
same settings in the SETUP menu. Refer to “Adjusting the
volume (VOL LV ADJ)” on page 24.
*14 Refer to “Setting the BLUETOOTH sound quality” on
page 24.
*15 While calling, the call sound can be switched between the
unit and mobile phone by using this setting.
This operation can also be done by pressing BAND. Refer to
“Call Switching Operation” on page 27.
*16 While calling, and the Voice Mute is activated, the
microphone input will mute instantly and “VOICE MUTE”
will blink. This operation can also be done by pressing .
Refer to “Muting the microphone input quickly (Voice Mute)”
on page 27.
*17 If there is a waiting call, select this item to display the caller’s
Name and waiting number (1 or 2). Press k and the
display will switch.
*18 Select this item to hang up the call.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
* The illustration is for CDE-SXM145BT/CDE-143BT.
Setting
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, GENERAL Setting, DISPLAY Setting,
etc., can be modified.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select the desired item, and
then press ENTER.
(e.g. Select GENERAL)
AUDIO
*1
 GENERAL  DISPLAY  TUNER  SIRIUSXM
*2

iPod  BLUETOOTH
*3
GENERAL:
CLOCK ADJ
*4
 AUX SETUP
*5
 AUX NAME
*6
 PLAY MODE
*7
 DEMO
DISPLAY:
DIMMER  TEXTSCROLL  SCROLLTYPE
TUNER:
FM SET
iPod:
iPod LIST
*1 Refer to “Audio Setup” on page 15.
*2 Displayed only when a SiriusXM Tuner is connected. For
details, refer to “SiriusXM Setting (CDE-SXM145BT Only)” on
page 32. (CDE-SXM145BT Only)
*3 Refer to “BLUETOOTH SETUP” on page 23.
*4 Refer to “Setting Time” on page 10.
*5 Not displayed when the current source is AUXILIARY.
*6 Displayed only when AUX SETUP is set to ON.
*7 CDE-SXM145BT/CDE-143BT only.
3 Turn the Rotary encoder to select a setting item, and then
press ENTER.
(e.g. Select AUX SETUP)
4 Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select AUX ON or AUX OFF.)
SETUP
Use steps 1 to 5 to select one of the SETUP modes to modify.
See the applicable section below for details about the
selected SETUP item.
AUDIO/SETUP
/ENTER

SOURCE/

Rotary encoder

Alpine CDE-143BT Specifications

General

MP3 playback	Yes
AM band range	530 - 1710 kHz
FM band range	87.7 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	18
DIN size	1 DIN
Output power	200 W
Product color	Black
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP

Weight and Dimensions

Weight	15000 g
Dimensions (WxDxH)	178 x 161 x 50 mm
