39-EN
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD PLAYER SECTION
USB SECTION
PICKUP
BLUETOOTH SECTION
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
CAUTION
Tuning Range 87.5 ~ 108.0 MHz
Mono Usable Sensitivity 0.7 μV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531 ~ 1,602 kHz
Sensitivity (IEC Standard) 25.1 μV/28 dB
Tuning Range 153 ~ 281 kHz
Sensitivity (IEC Standard) 31.6 μV/30 dB
Frequency Response 5 ~ 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption Smartphone charge-capable
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media
™
Audio
AAC Decoding AAC-LC format “.m4a” file
Wave length 795 nm
Laser power CLASS I
BLUETOOTH Specification Bluetooth v2.1 + EDR
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
HSP (Head Set Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Power Requirement 14.4 V DC
(11 ~ 16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±9.1 dB at 100 Hz
Treble ±9.1 dB at 10 kHz
Weight 1.37 kg (3 lbs)
Width 178 mm (7")
Height 50 mm (2")
Depth 161.5 mm (6–3/8")
Width 170 mm (6–3/4")
Height 45 mm (1–3/4")
Depth 24 mm (15/16")
CLASS 1
LASER PRODUCT
(Bottom side of player)
