74-EN
Wi-Fi SECTION
Frequency Ranges IEEE 802.11 b/g/n (2.4 GHz)
IEEE 802.11 a/n/ac (5 GHz)
Channels 1 – 11 ch (2.4 GHz)
149 – 165 ch (5 GHz)
Security Protocols WPA3 / WPA2-PSK (TKIP, AES)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Operating temperature -4°F to +140°F
(-20°C to + 60°C)
Power Output 18 W RMS × 4 *
2
*2 Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
Maximum Current Consumption
15 A
Audio output level
Preout (Front, Rear): 4V/10k ohms (max.)
Preout (Subwoofer): 4V/10k ohms (max.)
Weight 1.4 kg (3 lbs. 2 oz) (iLX-507)
2.3 kg (5 lbs. 2 oz) (iLX-F509)
2.6 kg (5 lbs. 12 oz) (iLX-F511)
1.6 kg (3 lbs. 9 oz) (i509)
CHASSIS SIZE
iLX-507 iLX-F509 iLX-F511 i509
Width 178 mm
(7 1/8”)
178 mm
(7 1/8”)
178 mm
(7 1/8”)
178 mm
(7 1/8”)
Height 50 mm
(2”)
50 mm
(2”)
50 mm
(2”)
50 mm
(2”)
Depth 149.6 mm
(6”)
149.6 mm
(6”)
149.6 mm
(6”)
142 mm
(5 5/8”)
DISPLAY SIZE
iLX-507 iLX-F509 iLX-F511 i509
Width 171 mm
(6 3/4”)
232.5 mm
(9 1/4”)
268.9 mm
(10 5/8”)
215.5 mm
(8 1/2”)
Height 96 mm
(3 7/8”)
151.1 mm
(6”)
178 mm
(7 1/8”)
133.8 mm
(5 3/8”)
Depth 17.7 mm (
23/32”)
54.7 mm
(2 1/4”)
54.7 mm
(2 1/4”)
37.8 mm
(1 1/2”)
• Due to continuous product improvement, specifications and
design are subject to change without notice.
• The LCD panel is manufactured using an extremely high
precision manufacturing technology. Its effective pixel ratio is
over 99.99%. This means that there is a possibility that 0.01%
of the pixels could be either always ON or OFF.
