#6001 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 11
Type of Oven counter counter counter counter floor floor
oven stand oven stand oven stand oven stand w/roll-in cart w/roll-in cart
Pan INCHES 6: 12" x 20" 10: 12" x 20" 14: 12" x 20" 20: 12" x 20" 24: 12" x 20" 40: 12" x 20"
Capacity 6: 18" x 13" 10: 18" x 13" 7: 18" x 26" 10: 18" x 26" 12: 18" x 26" 20: 18" x 26"
GASTRONORM 6: GN 1/1 10: GN 1/1 14: GN 1/1 20: GN 1/1 24: GN 1/1 40: GN 1/1
12: GN 2/1 20: GN 2/1
Side Rack INCHES 2-5/8 2-5/8 2-5/8 2-5/8 2-5/8 2-5/8
Spacing (MILLIMETERS) (65mm) (65mm) (65mm) (65mm) (65mm) (65mm)
Interior INCHES 23-1/2 23-1/2 23-1/2 23-1/2 26-1/4 26-1/4
Width (MILLIMETERS) (596) (596) (596) (596) (667) (667)
Interior INCHES 21-1/16 21-1/16 28-7/16 28-7/16 32-11/16 32-11/16
Depth (MILLIMETERS) (535) (535) (722) (722) (830) (830)
Interior INCHES 17-3/4 27 20-5/16 30-3/4 38-11/16 60-1/4
Height (MILLIMETERS) (451) (685) (515) (781) (983) (1530)
Noise
Level
Spray Hose 81-inches 81-inches 87-inches 87-inches 87-inches 102-inches
Length (2050mm) (2050mm) (2200mm) (2200mm) (2200mm) (2600mm)
Water Consumption 5 -8 gal/hr 8-13 gal/hr 8-13 gal/hr 10.5-18.5 gal/hr 13-21 gal/hr 21-26.5 gal/hr
(
APPROX.) (20-30 l/hr) (30-50 l/hr) (30-50 l/hr) (40-70 l/hr) (50-80 l/hr) (80-100 l/hr)
Steam Generator
Water Consumption
0.05 gal/min 0.10 gal/min 0.10 gal/min 0.13 gal/min 0.16 gal/min 0.21 gal/min
(
APPROX.) (0.2 l/min) (0.4 l/min) (0.4 l/min) (0.5 l/min) (0.6 l/min) (0.8 l/min)
Steam Generator 27.7 lb/hr 46.3 lb/hr 46.3 lb/hr 69.2 lb/hr 83.3 lb/hr 111.1 lb/hr
Rating (APPROX.) (12.6 kg/hr) (21 kg/hr) (21 kg/hr) (31.4 kg/hr) (37.8 kg/hr) (50.4 kg/hr)
Steam
Generator
GALLONS 1.3 2.6 2.6 4.0 4.0 5.3
Volume (LITERS) (5) (10) (10) (15) (15) (20)
Radiated
Heat
BTU/HR 2823 4419 4419 6874 8592 15729
Loss (KJ/H) (2981) (4666) (4666) (7258) (10368) (16608)
Latent
Heat
BTU/HR 2945 4909 4909 6750 8101 11783
Loss (kJ/h) (3110) (5184) (5184) (7128) (8554) (12442)
Total
Heat
BTU/HR 5768 9328 9328 13624 16693 27513
Loss (kJ/h) (6091) (9850) (9850) (14386) (17626) (29050)
Air Circulation
(WITH/WITHOUT HOOD)
cubic feet/hr 10170/8122 16951/13419 16951/13419 27121/21541 33902/26839 67804/54031
▲▲ T=8K (m
3
/h) (288/230) (480/380) (480/380) (768/610) (960/760) (1920/1530)
Air Circulation
(WITH/WITHOUT HOOD)
cubic feet/hr 6356/4590 10594/7416 10594/7416 15891/11300 19069/13419 25426/18363
▲▲ x=5g/kg (m
3
/h) (180/130) (300/210) (300/210) (450/320) (540/380) (720/520)
ADDITIONAL TECHNICAL DATA
6•10ML 10•10ML 7•14ML 10•18ML 12•20ML 20•20ML
MODEL ➜➜
The noise emission level related to the workplace is lower than: 70 dBA
