03_01
Engine oil level check (03_01)
•
Check the oil level as indicated in the maintenance tables.
•
Park the vehicle on its centre stand.
NOTE
EVERY TIME THE SCOOTER IS USED, CHECK ENGINE OIL LEVEL WHEN THE
ENGINE IS COLD.
•
Unscrew and take out the measuring tap-dipstick «1».
•
Clean the area in contact with oil with a clean cloth.
•
Screw the tap-dipstick «1» completely in its tube «2».
•
Remove the tap-dipstick «1» again and read the level the oil reaches on the
dipstick.
•
The level is correct when it is close to the maximum notch marked on the
measuring dipstick.
•
Top up if necessary.
The MAX level reference indicates a quantity of about 850 cc of oil in the engine. If
the check is carried out after the vehicle has been used, and therefore with a hot
engine, the level line will be lower; in order to carry out a correct check, it is necessary
to wait for at least 10 minutes after the engine has been stopped so as to get the
correct level.
61
