APRILIA MOJITO 125 Owner's Manual

Tail lights and low-beam light
warning light
12V - 1.2W
High-beam warning light 12V - 1.2W
Turn indicator warning light 12V - 2W
Engine oil pressure warning light 12V - 2W
Low fuel warning light 12V - 2W
03_16
Front light group (03_16, 03_17, 03_18, 03_19)
In the front headlight there are:
•
one tail light bulb «1»;
•
one low-/high-beam light bulb «2» (halogen).
03_17
To reach the bulbs:
•
Park the vehicle on its centre stand.
•
Undo and remove the screw «16» (operate both sides of the vehicle).
•
Remove the headlamp ring nut «17».
NOTE
UPON REFITTING, INSERT THE FIXING TAB «18» CORRECTLY IN ITS SLOT.
82
3 Maintenance

APRILIA MOJITO 125 Specifications

General

Displacement	124 cc
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Engine Type	Single cylinder, 4-stroke
