11
use and maintenance Pegaso 650 I.E. STRADA - TRAIL
KEY
1) Tail light
2) Passenger grab rail
3) Seat
4) Rear brake fluid tank
5) Air filter
6) Rear shock absorber
7) Engine oil level plug-dipstick
8) Front brake fluid tank
9) Right rear-view mirror
10) Horn
11) Engine oil filter
12) Rear brake control lever
13) Rider right footrest
14) Rear brake master cylinder
15) Passenger right footrest
(snapping, closed/open)
16) Coolant expansion tank
cap
17) Coolant expansion tank
18) CO sensor plug
1
3 5
17
16
10
6 94
15 14
2
7
8
1213 11
18
Pegaso650IE-E.book Page 11 Tuesday, September 26, 2006 5:51 PM
