85
use and maintenance Pegaso 650 I.E. STRADA - TRAIL
3 8
7
HIGH BEAM BULB
u Turn the high beam unit counter
clockwise (4).
u Grasp the electric terminal (5), pull it and
disconnect it from the bulb (1).
u Withdraw the bulb (1) and replace it with
a new one of the same type.
NOTE Insert the bulb in the bulb holder,
making the relevant positioning seats
coincide.
PARKING LIGHT BULB
CAUTION
To extract the bulb holder, do not pull
the electric wires.
u Grasp the parking light bulb holder (6)
and pull to extract.
u Withdraw the bulb (2) and replace it with
one of the same type.
LOW BEAM BULB
u Turn the low beam unit counter
clockwise (7).
u Grasp the electric terminal (8), pull it and
disconnect it from the bulb (3).
u Withdraw the bulb (3) and replace it with
a new one of the same type.
6
2
1 514
Pegaso650IE-E.book Page 85 Tuesday, September 26, 2006 5:51 PM
