TECHNICAL DATA TABLE
DESCRIPTION
Unit 200 250 250 SYS
250 TWIN
SYS
Rated tank capacity
l 200 250 245 240
Insulation thickness
mm ≈ 50
Type of internal tank protection
smaltatura
Type of corrosion protection
Titanium impressed current anode + disposable
magnesium anode
Maximum operating pressure
MPa 0,6
Diameter of hydraulic connections
II G 3/4 M
Diameter of condensate drainage connection
mm 14
Diameter of air exhaust/intake pipes
mm 150-160-200
Minimum water hardness
°F 12
Minimum conductivity of the water
μS/cm 150
Weight when empty
kg 90 95 115 130
Heating bottom circuit exchange surface
m² - - 0,65 0,65
Heating top circuit exchange surface
m² - - - 0,65
Max water temperature with external integration
°C - - 75 75
HEAT PUMP
Average electrical power consumption
W 700
Max. electrical power consumption
W 900
Quantity of refrigerant fluid (R134a)
kg 1,3
Quantity of fluorinated greenhauses gases (R134a)
Tonn. CO
2
eq. 1,859
Global warning potential (R134a)
GWP 1430
Max. pressure of refrigerating circuit (low-pressure side)
MPa 1
Max. pressure of refrigerating circuit (high-pressure side)
MPa 2,7
Max. water temperature with heat pump
°C 62
EN 16147 (
A
)
COP (
A
)
3,10 3,35 3,14 3,21
Heating time (
A
)
h:min 03:59 05:23 05:24 05:15
Heating energy consumption (
A
)
kWh 2,478 3,346 3,264 3,224
Max. amount of hot water in a single intake Vmax (
A
), delivered at 55°C
l 256 336 333 325
Pes (
A
)
W 21 22 23 25
Tapping (
A
)
L XL XL XL
812/2013 – 814/2013 (
B
)
Qelec (
B
)
kWh 3,72 5,66 6,04 5,86
η
wh (
B
)
% 130,0 138,0 129,0 133,0
Mixed water at 40°C V40 (
B
)
l 256 336 333 325
Temperature setting (
B
)
°C 55 55 55 55
Annual electricity consuption (average climatic condition) (
B
)
kWh/anno 790 1215 1299 1256
Load prifile (
B
)
L XL XL XL
Indoor sound power level (
C
)
dB(A) 55 55 55 55
HEATING ELEMENT
Heating element power
V / W Check product specification label
Max. water temperature with heating element
Hz 50
Max. current consumption
IPX4
POWER SUPPLY
Voltage / max. power consumption
V / W Check product specification label
Frequency
Hz 50
Protection rating
IPX4
AIR SIDE
Standard air flow rate (automatic modulating control) m³/h 650
Available static pressure
Pa 110
Minimum volume of room of installation (
D
)
m³ 30
Minimum ceiling height of room of installation (
D
)
m 1,940 2,200 2,200 2,200
Min. temperature of room of installation
°C 1
Max. temperature of room of installation
°C 42
Minimum air temperature (w.b. a 90% u.r.) (
E
)
°C -7
Maximum air temperature (w.b. a 90% u.r.) (
E
)
°C 42
Further energy data is shown in the Product Data Sheet (Annex A) which is an integral part of this booklet. Products without a label and relative dia-
grams for water heater units and solar heating devices, specified by Regulation 812/2013, are not intended for use in manufacturing such units.
(A) Values obtained with outdoor air temperature of 7°C and relative humidity of 87%, inlet water temperature of 10°C and temperature set at 55°C (as per the provisions in EN 16147 and CDC
103-15/C-2018). Ducted product Ø200 mm.
(B) Values obtained with outdoor air temperature of 7°C and relative humidity of 87%, inlet water temperature of 10°C and temperature set at 55°C (as per the provisions of 2014/C 207/03 - tran-
sitional methods of measurement and calculation). Ducted product Ø200 mm.
(C) Values obtained from the average of the results as per the provisions in EN 12102-2. Ducted product Ø200 mm.
(D) Value that guarantees the correct operation and easy maintenance with non-ducted products. The correct operation of the product is nevertheless guaranteed up to a minimum height of
2.090 m.
(E) Beyond the heat pump temperature range of operation, heating of the water is ensured by integration (as per provisions of EN 16147).
