ASROCK Rack X570D4U User Manual

2 3
English
1.2 Specications
X570D4U
X570D4U-2L2T
X570D4U-2L2T/BCM
Physical Status
Form Factor Micro-ATX
Dimension 9.6" x 9.6" (244 mm x 244 mm)
Processor System
CPU AMD Ryzen™ 5000, 4000 and 3000 G-Series Desktop
Processors with Radeon™ Graphics
AMD Ryzen™ 5000 and 3000 Series Desktop Processors
AMD Ryzen™ PRO 5000, 4000 and 3000 Series Desktop
Processors
Socket 1 Socket AM4 (PGA 1331)
ermal Design
Power (TDP)
105W
Chipset AMD X570
System Memory
Supported DIMM
Quantity
4 DIMM slots (2DPC)
Supported Type DDR4 288-pin ECC*/non-ECC UDIMM
Max. Capacity per
DIMM
32GB
Max. DIMM
Frequency
3200 MHz**
Voltage 1.2V
Note *For AMD Ryzen™ Desktop Processors with Radeon Graphics, ECC support is
only with Processors with PRO technologies.
**AMD Ryzen™ 3000 G-Series Desktop Processors with Radeon™ Graphics
support up to 2666 MHz
Expansion Slot
SLOT6 PCIe4.0 x16 [CPU]
SLOT5 PCIe4.0 x1 [FCH]
SLOT4 PCIe4.0 x8 [CPU]
Note -SLOT6 auto-switch to PCIe4.0 x8 when SLOT4 occupied
-SLOT6 supports PCIe3.0 only when installing AMD Ryzen™ 5000, 4000 G-
Series Desktop Processors with Radeon™ Graphics
-SLOT6 supports PCIe3.0 x8 only when installing AMD Ryzen™ 3000 G-Series
Desktop Processors with Radeon™ Graphics
-SLOT5 supports PCIe3.0 only when installing AMD Ryzen™ 5000, 4000 and
3000 G-Series Desktop Processors with Radeon™ Graphics
-SLOT4 supports PCIe3.0 only when installing AMD Ryzen™ 5000, 4000 G-
Series Desktop Processors with Radeon™ Graphics
-SLOT4 will not function when installing AMD Ryzen™ 3000 G-Series Desk-
top Processors with Radeon™ Graphics"
