Bedienungsanleitung Counter AC-10 AC-15 09/2020 Seite 20 von 37
Operating instructions Counter AC-10 AC-15
o The step size can have the following values: 1, 5, 10, 20, 30, 40, 50
o The countstop is 1000.
• Free
o The countstop can be set between 10 and 1000, in steps of 10 and 100.
o Exclusive keys are selected by the user.
Once the desired program is selected, it must be confirmed with the "Enter/Go On" key. The display then
changes to the step size or final value setting.
Alternatively, in this phase of the "Setup" mode, the last count performed can be corrected. To do this,
press any count button. If the end counter of the last created count data, is not equal to the countstop, the
count will be recalled automatically so that counting can continue immediately after the unit is started.
3.3 Set countstop/stepwidth
If the "Reti" program is selected, the step size is set in this step. This is done using the "Right/+" or "Left/-
/Eval." keys. The step size is set after the sequence 1, 5, 10, 20, 30, 40, 50. The input of the "Left/-/Eval."
key is ignored if the step size is 1. Pressing the "Right/+" key has no effect on the step size if it is 50.
Similarly, if the "Reti" program is not selected, the final value is set with the same keys. By keeping the key
pressed, the final value is incremented/decremented in steps of 10. By simply pressing the keys, the final
value is changed in steps of 100.
The setting of the final value or the step size is confirmed by pressing the "Enter/Go On" key.
3.4 Choose exclusive keys
If the "Free" program is selected, the exclusive keys are selected after setting the final value. This is done by
pressing any count keys. Pressing a key that has not been exclusively evaluated marks it as an exclusive key.
